TTM DC N25 Metal Geared Motor with Encoder
TT Motor – N25 6V 1330RPM Metal Gear Motor With Encoder D Type Shaft
- Model: N25
- Type: Metal Gear Motor With Encoder D type Shaft
- Operating Voltage: 6V
- Rated RPM: 1330
SKU: Not Found
Brand: TT Motors
Out of stock
₹583.00
Free Delivery Expected:
Thursday, May 28 - Saturday, May 30
Order within the next 16 hrs to get it by this date.
- 100% Secure Checkout
- 7-Day Easy Returns
- Authentic & Quality Checked
- 24/7 Priority Support
Product Description
The N25 6V 1330RPM Metal Gear Motor with D-Type Encoder offers precision and reliability. Its robust metal gears provide durability and efficient power transmission. Operating at 6V with a high speed of 1330 RPM, the motor features a built-in D-type encoder for accurate rotation monitoring. Ideal for applications demanding precise motion control and position feedback, such as robotics, automation, and electronics projects.
Explore and select from all variants that matches to your requirements:
| SKU | Name | Voltage(V) | RPM |
| 1607490 | N25 Metal Gear Motor With Encoder D Type Shaft | 12 | 75 |
| 1607491 | N25 Metal gear Motor With Encoder D type | 6 | 115 |
| 1607488 | N25 Metal gear Motor With Encoder D Type Shaft | 12 | 170 |
| R207441 | N25 Metal Gear Motor With Encoder | 6 | 260 |
| 1607489 | N25 Metal Gear Motor With Encoder D type | 12 | 370 |
| 1607495 | N25 Metal Gear Motor With Encoder D Type Shaft | 6 | 550 |
| 1607493 | N25 Metal Gear Motor With Encoder D Type Shaft | 6 | 1330 |
Features:
- N25 6V 1330RPM Metal Gear Motor
- Includes D-Type Encoder
- Sturdy metal gears ensure durability
- Operating voltage: 6V
- High speed: 1330 RPM
- Suitable for robotics, automation, and electronics applications
Package Includes:
1 x N25 6V 1330RPM Metal Gear Motor With Encoder D Type Shaft
Technical Specifications
| Item Type | N25 Metal Gear Motor |
|---|---|
| Length (mm) | 59 |
| Operating Voltage (V) | 6 |
| Rated Speed (RPM) | 1330 |
| Shaft Diameter (mm) | 2.6 |
| Shaft Length (mm) | 9 |
| Shaft Type | D Type |
| Shipping Dimensions | 10 × 7 × 2 cm |
| Shipping Weight | 0.096 kg |
| Weight (g) | 94 |
