TTM DC N25 Metal Geared Motor with Encoder
N25 6V 260 RPM Metal Gear Motor With Encoder
- Motor Type: N25 TT motor.
- Voltage: 6V DC.
- Speed: 260 RPM.
- Gearbox: Metal.
- Encoder: Integrated.
SKU: Not Found
Brand: TT Motors
Out of stock
₹540.00
Free Delivery Expected:
Thursday, May 28 - Saturday, May 30
Order within the next 16 hrs to get it by this date.
- 100% Secure Checkout
- 7-Day Easy Returns
- Authentic & Quality Checked
- 24/7 Priority Support
Product Description
The TT motor N25 is a 6V DC motor featuring a robust metal gearbox and an integrated encoder. This motor is designed for applications requiring precise speed and position control. With a rated speed of 260 RPM, it provides a balance of speed and torque. The integrated encoder allows for accurate feedback, enabling closed-loop control systems. The metal gearbox enhances durability and longevity, making it suitable for demanding robotic and automation projects.
Explore and select from all variants that matches to your requirements:
| SKU | Name | Voltage(V) | RPM |
| 1607490 | N25 Metal Gear Motor With Encoder D Type Shaft | 12 | 75 |
| 1607491 | N25 Metal gear Motor With Encoder D type | 6 | 115 |
| 1607488 | N25 Metal gear Motor With Encoder D Type Shaft | 12 | 170 |
| R207441 | N25 Metal Gear Motor With Encoder | 6 | 260 |
| 1607489 | N25 Metal Gear Motor With Encoder D type | 12 | 370 |
| 1607495 | N25 Metal Gear Motor With Encoder D Type Shaft | 6 | 550 |
| 1607493 | N25 Metal Gear Motor With Encoder D Type Shaft | 6 | 1330 |
Features:
- N25 6V 260 RPM Metal gear Motor
- Built-in D-Type Encoder
- Durable metal gears
- 6V operating voltage
- 260 RPM speed
- Ideal for robotics and automation
Package Includes:
1 x N25 6V 260 RPM Metal gear Motor With Encoder
Technical Specifications
| Item Type | N25 Metal Gear Motor |
|---|---|
| Model No | GM25 370CA 22170 21EN |
| Model Series | N25 |
| Motor Type | Metal Gear Motor |
| Rated Speed (RPM) | 260 |
| Rated Voltage (V) | 6V |
| Shaft Diameter (mm) | 4 |
| Shaft Length (mm) | 1.2 |
| Shaft Type | D |
| Shipping Dimensions | 12 × 7 × 2 cm |
| Shipping Weight | 0.109 kg |
| Weight (g) | 108 |
