The Hanyoung Nux T57NE-10A Analog On delay Timer is a sophisticated electronic control device designed to offer precise timing functionality in various industrial and commercial applications. This timer is renowned for its accuracy, reliability, and user-friendly operation, making it an essential component in automation, manufacturing, and control systems.

Features:

1. Precise Timing Control
2. Adjustable Time Range
3. Analog Input Compatibility
4. User-Friendly Interface
5. LED Status Indicators
6. Output Activation
7. DIN Rail Mounting
8. Robust Build Quality
9. Versatile Applications
10. Reliable Performance
11. Flexible Integration

Specifications:

1. Life span of relay Mechanical : More than 10 million times / Electrical : More than 100,000 times
2. Dielectric strength: 2000 V a.c 50 / 60 Hz for 1 minute
3. Noise Immunity ±2 kV (Between unit’s power terminals), square wave by noise simulator (pulse width : 1 ㎲)
4. Insulation resistance More than 100 ㏁ (Based on 500 V DC mega standard)
5. Vibration(Durability): 10 – 55 ㎐ (cycle :1 minute), Double amplitude 0.5 ㎜ X·Y·Z each direction for 2h.
6. Shock(Durability): 300 m/s² (30 G) X Y Z each direction 3 times
7. Ambient temperature: – 10 ~ 55 °C Without freeze
8. Storage temperature: – 25 ~ 65 °C Without freeze
9. Ambient humidity: 30 ~ 85 % R.H.
10. Function POWER ON DELAY TIMER
11. Power supply: 24 – 240 V a.c 50 / 60Hz, 24 – 240 V d.c ( ±10 %)
12. Allowable voltage variation ± 10 % of Power supply voltage
13. Power Consumption Less than 4.5 VA (at 240 V a.c 60 Hz), Less than 1.5 W (at 24 V d.c)
14. Return time Less than: 100 ms

Package Includes:

1 x T57NE-10A Analog On delay Timer
