TTM DC N20 Metal Geared Motor with Encoder
TT Motor – N20 24V 55RPM Metal Gear Motor With Encoder D Type Shaft
- Model: N20
- Type: Metal Gear Motor With Encoder D-Type Shaft
- Operating Voltage: 24V
- Rated RPM: 55
SKU: Not Found
Brand: TT Motors
Out of stock
₹399.00
Free Delivery Expected:
Thursday, May 28 - Saturday, May 30
Order within the next 15 hrs to get it by this date.
- 100% Secure Checkout
- 7-Day Easy Returns
- Authentic & Quality Checked
- 24/7 Priority Support
Product Description
The N20 24V 55RPM Metal Gear Motor with D-type Encoder offers robust and efficient motion control. With a durable metal gearbox and precise encoder, it ensures reliable and accurate performance. Operating at 24V, it achieves a speed of 55 RPM, making it suitable for applications requiring controlled rotation. The D-type encoder provides essential feedback for precise position monitoring. This motor is a great fit for projects that demand dependable and controlled motor functions, such as robotics, automation, and industrial applications.
Explore and select from all variants that matches to your requirements:
| SKU | Name | Voltage(V) | RPM |
| 1607480 | N20 Metal Gear Motor With Encoder D Type Shaft | 12 | 52 |
| 1607483 | N20 Metal Gear Motor With Encoder D Type Shaft | 24 | 55 |
| 1607486 | N20 Metal Gear Motor With Encoder D Type Shaft | 6 | 65 |
| 1607484 | N20 Metal Gear Motor With Encoder D Type Shaft | 24 | 90 |
| 1607487 | N20 Metal Gear Motor With Encoder D Type Shaft | 6 | 125 |
| 1607478 | N20 Metal Gear Motor With Encoder D Type Shaft | 12 | 125 |
| 1607479 | N20 Metal gear Motor With Encoder D type | 12 | 135 |
| 1607481 | N20 Metal Gear Motor With Encoder D Type Shaft | 24 | 175 |
| 1607485 | N20 Metal Gear Motor With Encoder D Type Shaft | 6 | 240 |
| 1607482 | N20 Metal Gear Motor With Encoder D Type Shaft | 24 | 340 |
Features:
- N20 24V 55RPM Metal Gear Motor with D-type Encoder
- Sturdy metal gearbox for durability
- Accurate D-type encoder for reliable feedback
- Operates efficiently at 24V
- Achieves a speed of 55 RPM
- Ideal for controlled rotation needs
- Suitable for robotics, automation, and industrial applications
Package Includes:
1 x N20 24V 55RPM Metal Gear Motor With Encoder D Type Shaft
Technical Specifications
| Length (mm) | 60 |
|---|---|
| Operating Voltage (V) | 24 |
| Rated Speed (RPM) | 55 |
| Shaft Diameter (mm) | 4 |
| Shaft Length (mm) | 8 |
| Shaft Type | D Type |
| Shipping Dimensions | 10 × 7 × 2 cm |
| Shipping Weight | 0.06 kg |
| Weight (g) | 59 |
