TTM DC N20 Metal Geared Motor with Encoder
TT Motor – N20 12V 135RPM Metal gear Motor With Encoder D type
- Model: N20
- Type: Metal gear Motor With Encoder D type
- Voltage: 12V
SKU: Not Found
Brand: TT Motors
Out of stock
₹466.00
Free Delivery Expected:
Thursday, May 28 - Saturday, May 30
Order within the next 15 hrs to get it by this date.
- 100% Secure Checkout
- 7-Day Easy Returns
- Authentic & Quality Checked
- 24/7 Priority Support
Product Description
This is a high-quality and versatile motor designed to provide precise motion control and accurate feedback in various applications. This motor is engineered to deliver a blend of power and precision, making it an excellent choice for robotics, automation, and projects that demand controlled movement and reliable position sensing
Explore and select from all variants that matches to your requirements:
| SKU | Name | Voltage(V) | RPM |
| 1607480 | N20 Metal Gear Motor With Encoder D Type Shaft | 12 | 52 |
| 1607483 | N20 Metal Gear Motor With Encoder D Type Shaft | 24 | 55 |
| 1607486 | N20 Metal Gear Motor With Encoder D Type Shaft | 6 | 65 |
| 1607484 | N20 Metal Gear Motor With Encoder D Type Shaft | 24 | 90 |
| 1607487 | N20 Metal Gear Motor With Encoder D Type Shaft | 6 | 125 |
| 1607478 | N20 Metal Gear Motor With Encoder D Type Shaft | 12 | 125 |
| 1607479 | N20 Metal gear Motor With Encoder D type | 12 | 135 |
| 1607481 | N20 Metal Gear Motor With Encoder D Type Shaft | 24 | 175 |
| 1607485 | N20 Metal Gear Motor With Encoder D Type Shaft | 6 | 240 |
| 1607482 | N20 Metal Gear Motor With Encoder D Type Shaft | 24 | 340 |
Features:
- Easy to use
- Easy to install
- Good quality Product
Package Includes:
1 x N20 12V 135RPM Metal gear Motor With Encoder D type
Technical Specifications
| Current (A) | 20mA |
|---|---|
| Motor RPM | 135 RPM |
| Operating Voltage (V) | 12 |
| Rated Speed (RPM) | 135 |
| Shaft Type | D Type |
| Shipping Dimensions | 12 × 8 × 3 cm |
| Shipping Weight | 0.06 kg |
