Waveshare RPi Camera (I), Fisheye Lens
- Model: Waveshare RPi Camera
- Sensor best resolution: 1080p
- CCD size: 1/4inch
- Aperture (F): 2
- Focal Length: 1.55mm
SKU: Not Found
Brand: WAVESHARE
- 100% Secure Checkout
- 7-Day Easy Returns
- Authentic & Quality Checked
- 24/7 Priority Support
Product Description
Raspberry Pi Camera Module, Fisheye Lens, Wider Field Of View After the Bullseye version of the Raspberry Pi image, the underlying Raspberry Pi driver was switched from Raspicam to lib-camera. lib-camera is an open-source software stack (will be called driver later, which is easy to understand), which is convenient for third-party porting and development of their own camera drivers. As of 2021-12-20, there are still many bugs in lib-camera, and the current lib-camera does not support python, so the Raspberry Pi official still provides a method for installing and downloading Raspicam. For users who are difficult to switch to lib-camera but need to use the latest system, please directly refer to the Raspicam instructions.
Features:
- Raspberry Pi Camera
- Supports all revisions of the Pi
- Fisheye Lens, offers wider field of view
- 5 megapixel OV5647 sensor
- Adjustable focus distance
- Best for IoT projects
- Low power consumption
Package Include:
1 X RPi Camera (I)
1 X 15-pin FFC (opposite sides contact)
Technical Specifications
| Angle of View (diagonal) | 185 degree (while other normal cameras are typically 72 degree) |
|---|---|
| Aperture (F) | 2 |
| Camera Type | Fisheye Lens |
| CCD Size | 1/4inch |
| Focal Length (mm) | 1.55mm |
| Item Type | Camera Module |
| Net Weight | 17g |
| Operating Voltage (V) | 3.3 |
| Picture resolution | 2592 x 1944 |
| Resolution | 5MP (2592 x 1944) |
| Sensor best resolution | 1080p |
| Shipping Dimensions | 8 × 7 × 3 cm |
| Shipping Weight | 0.027 kg |
| Supported | 1080p 30, 720p 60 and 640 x 480p 60/90 video record |
