Waveshare Dedicated Cooling fan for Jetson Nano, Built-in Speed-Adjustable Fan compatible With JETSON NANO MINI
- Compatible with NVIDIA Jetson Nano
- Built-in PWM speed-adjustable fan
- 5500±10% RPM high-speed cooling
- Durable aluminum alloy enclosure
- Easy install with elastic bracket
- Power-efficient at just 0.65W
SKU: Not Found
Brand: WAVESHARE
- 100% Secure Checkout
- 7-Day Easy Returns
- Authentic & Quality Checked
- 24/7 Priority Support
Product Description
Keep your NVIDIA Jetson Nano running cool and stable with the Waveshare Dedicated Cooling Fan. Designed specifically for the Jetson Nano module, this fan features a built-in PWM speed-adjustable fan capable of reaching 5500±10% RPM. Its integrated aluminum alloy enclosure provides both durability and effective heat dissipation. The fan comes with an elastic bracket and height-limited screws, making installation quick and secure. Powered by a 5V DC input and consuming only 0.65W, it offers high performance while remaining energy-efficient. Whether you’re building AI projects or running intensive workloads, this fan ensures your Jetson Nano stays efficient and cool under pressure.
Features:
- Purpose-built for Jetson Nano
- PWM speed-adjustable fan for efficient cooling
- Aluminum alloy casing for robust heat dissipation
- Compact and low-power operation (0.65W)
- Easy mounting with elastic bracket & screws
- Quiet, high-RPM operation for optimal airflow
Package Includes:
1 x Waveshare Dedicated Cooling fan for Jetson Nano, Built-in Speed-Adjustable Fan compatible With JETSON NANO MINI
1 x Elastic bracket and height-limited screws
Technical Specifications
| Cable length (mm) | 37±3 |
|---|---|
| Electrical Parameter | 0.65W (5V/0.13A) |
| Fan Type | PWM speed-adjustable |
| Height (mm) | 18 |
| Item Type | Cooling Fan |
| Length (mm) | 58 |
| Power Supply | DC 5V input |
| Rated Voltage (V) | 05 |
| Shipping Dimensions | 9 × 7 × 5 cm |
| Shipping Weight | 0.075 kg |
| Speed(rpm) | 5500±10% |
| Weight (g) | 62 |
| Width (mm) | 39 |
