12V Cooling Fans
Sunon 8025 12VDC 1.66W Cooling Fan
- Operating Voltage: 12VDC
- Power Consumption: 1.44W
- Body and Blade Constructed from Thermoplastic PBT of UL 94V-0
- Single Phase 4 Pole Brushless DC Motor
- Lubricated Sleeve Bearing System.
- Counterclockwise Rotation Direction if Viewed from front of Fan Blade
SKU: Not Found
Brand: Sunon
Out of stock
₹260.00
Free Delivery Expected:
Thursday, May 28 - Saturday, May 30
Order within the next 15 hrs to get it by this date.
- 100% Secure Checkout
- 7-Day Easy Returns
- Authentic & Quality Checked
- 24/7 Priority Support
Product Description
This is a High-Quality 80 x 25 mm size Cooling Fan from Sunon. The cooling fan consists of a 4-pole Brushless DC Motor with a precise lubricated sleeve bearing system, this coolingfan can deliver an airflow up to 41 CFM, which is sufficient enough to keep the electronics cool.
Find more details about the product in the attachment section
Features:
- High-Quality Fan with Good Air Flow
- Body and Fan Blade Made from Thermoplastic PBT of UL 94V-0
- Precise Vapo Bearing System
- Single Phase 4 Pole Brushless DC Motor
- Easy to use
Package Includes:
1 x Sunon 8025 12VDC 1.66W Cooling Fan
Technical Specifications
| Cable length (mm) | 300 |
|---|---|
| Color | Black |
| Dimensions (L x W x H) mm | 80×25 |
| Height (mm) | 80 |
| Insulation Class | UL Class A |
| Item Type | Regular Cooling Fan |
| Length (mm) | 80 |
| Material | Metal, Plastic |
| Noise Level (dB) | 33 |
| Power Consumption (W) | 1.66 |
| Rated Current (A) | 0.138 |
| Rated Speed (RPM) | 3200 |
| Rated Voltage (V) | 12 |
| Shipping Dimensions | 9 × 9 × 1 cm |
| Shipping Weight | 0.078 kg |
| Weight (g) | 75 |
| Width (mm) | 25 |
